Free Fall Lifeboat

Current Location: Home > Products > F.R.P Lifeboat
◆ After release the boat hook, boat freefall along the davit ramp and fall into water, good design of  boat body, satisfying the strength requirements of fall into water form ship, and complete avoid damage passage in boat.
◆ The fastest escape speed.



Free Fall Lifeboat Main Data:

Model

Main Dim.
(m)

Capacity
(P)

Length of Ramp
(m)

Speed
(knots)

Fall Height
(m)

Total weight
(kg)

JY-FN-4.9

4.90x2.25x0.86

16

5.9

>6

16

4040

JY-FF-4.9

4320

JY-FN-5.8

5.80x2.55x0.90

25

7.0

>6

17

5568

JY-FF-5.8

5898

JYM-FN-6.65

6.65x2.70x1.20

30

8.2

>6

21

6337

JYM-FF-6.65

6637

JY-FN-6.8

6.80x2.70x1.20

31

8.2

>6

22

6439.5

JY-FF-6.8

6739.5

JY-FN-7.5

7.50x2.70x1.20

35

9

>6

22

7374

JY-FF-7.5

7724

JY-FN-8.5

8.80x2.94x1.2

40

10.2

>6

25

8422

JY-FF-8.5

8722

JY-FN-9.5

9.50x3.23x1.06

51

11.3

>6

32

10810

JY-FF-9.5

11485

JY-FN-13.0

13.0x3.70x1.06

50*

18

>6

50

16500

JY-FF-13.0

17250

JY-FN-13.6

13.6x3.74x1.06

60*/75

16.3

>6

42

21140

JY-FF-13.6

21740

JY-FN-15.0

15.0x3.70x1.06

70*

15.6

>6

50

21250

JY-FF-15.0

22000

JY-FF-16.5

16.5x3.74x1.06

100

19.8

>6

42

25500


Note:
In the table:
"JY-FN-6.8/ JY-FF-6.8"
JY----JIAOYAN
FN----Normal type
FF----Fire Protected Type(with air supply system and water spraying system)
6.8----Boat Length

* Marker, Satisfy Requirement of DNV-OS-E406.
